Precision Audio Component / Double Cassette Deck DRW-585

Denon (Marke / brand)

Data
Forum
Pictures
Collections

  • Year
  • 1999
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 269864

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Cassette-Recorder or -Player; Remote Control (with wire or wireless)
  • Power type and voltage
  • Alternating Current supply (AC) / 120 or 230 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Precision Audio Component / Double Cassette Deck DRW-585 - Denon Marke / brand
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 434 x 135 x 263 mm / 17.1 x 5.3 x 10.4 inch
  • Notes

  • A frontloading hi-fi stereo double cassette deck with Dolby B, C and Hx-Pro. Optional remote control. Line Out and Line In RCA sockets, Synchronized Recording socket, jack for headphones.

    Features
    Computer Controlled Mechanism
    Dual Power Supply
    Dolby HX-Pro Headroom Extension System
    Dolby B & C Noise Reduction Systems
    Auto-Reverse record/playback
    MPX Filter Switch
    Non-slip Reel Drive
    Manual Bias Adjustment Control
    Dual Computing Tape Counter with 4-Digit Readout and Memory Stop
    Music Search System
    FL Peak Level Meters
    Auto Tape Selector
    Normal or High Speed Dubbing
    Relay Playback
    CD Synchronized Recording
    Timer Play and Timer Recording
    Tape Lighting

    Specification
    Type                        Vertical tape loading; 4-track 2-channel
                                    stereo double cassette deck
    Heads                      Playback head x 1 recording/playback head x 1
                                   Erase head (Double-gap ferrite) x 1
    Motors                     DC servo motor x 2
    Tape Speed              4.8 cm/sec.
    FF Rewind Time        Approx. 110 sec. with a C-60 cassette
    Recording Bias         Approx 105 kHz
    Overall S/ N Ratio
      (at 3% THD level)    Dolby C NR on: more than 74 dB (CCIR/ARM)
    Overall Frequency
      Response              20 — 17,000 Hz ±3 dB (at -20 dB. Metal tape)
    Channel Separation  More than 40 dB (at 1 kHz)
    Wow & Flutter         0.08% WRMS, ±0.14% w. peak
    Line Input                80 mV (-20 dBm) input level at maximum
    Input impedance      50 kΩ/kohms unbalanced
    Line Output             775 mV (0 dB) output level at maximum
                                   (with 47 kΩ/kohms load, recorded level of 200 pwb/mm)
    Power Consumption 16 Watts.

    Made in China

  • Net weight (2.2 lb = 1 kg)
  • 4 kg / 8 lb 13 oz (8.811 lb)
  • Mentioned in
  • -- Original prospect or advert (1999 Denon Product catalogue)
  • Literature/Schematics (1)
  • - - Manufacturers Literature (Instruction Manual, Service Manual)
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
