Precision Audio Component/Integrated Stereo Ampl. PMA-320

• Country
• Japan

• Manufacturer / Brand
• Denon (Marke / brand)

• Year
• 1989

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 219427

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Hi-Fi equipment

• Power type and voltage
• Alternating Current supply (AC) / 110-120; 220-240 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 180 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: Precision Audio Component/Integrated Stereo Ampl. PMA-320 - Denon Marke / brand

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 434 x 120 x 280 mm / 17.1 x 4.7 x 11 inch

• Notes
• Precision Audio Component/Integrated Stereo Amplifier PMA-320,
  2 x 90 Watt Sinusleistung (4 Ohm),
  2 x 60 Watt Sinusleistung (8 Ohm),
  2 x 120 Watt Musikleistung (4 Ohm),
  2 x 140 Watt Musikleistung (2 Ohm).

• Net weight (2.2 lb = 1 kg)
• 5.6 kg / 12 lb 5.4 oz (12.335 lb)

• Source of data
• -- Original prospect or advert
