- Country
- United States of America (USA)
- Manufacturer / Brand
- Detrola; Detroit (MI)
- Year
- 1939 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 37282
Beitman
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- AC/DC-set / 117 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 3201 - Detrola; Detroit MI
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 11 x 8 x 6 inch / 279 x 203 x 152 mm
- Notes
- Push Button Tuner. Carrying handle. The same Beitman schematic is for 320 Series, 3201 and 3202.
- External source of data
- Ernst Erb
- Source of data
- Machine Age to Jet Age II
- Circuit diagram reference
- Rider's Perpetual, Volume 11 = ca. 1940 and before
- Literature/Schematics (1)
- Beitman Radio Diagrams, Vol. 04, 1941
