unknown Luxor

DeWald Radio Mfg. Corp., Pierce Airo Inc.

Data
Forum
Pictures
Collections

  • Year
  • 1931 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 243533
    • Brand: Pierce Airo

 Technical Specifications

  • Number of Tubes
  • 5
  • Main principle
  • TRF without regeneration; 1 AF stage(s); Screengrid 1926-1935
  • Tuned circuits
  • 3 AM circuit(s)
  • Wave bands
  • Broadcast (MW) and Long Wave.
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 130; 140; 220; 240 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: unknown Luxor - DeWald Radio Mfg. Corp.,
  • Shape
  • Table-Cathedral-Type (upright, round top or gothic arch, not rounded edges only).
  • Dimensions (WHD)
  • 360 x 255 x 440 mm / 14.2 x 10 x 17.3 inch
  • Notes

  • One dial (primary tuning control knob). Probably made for the european market.



  • Net weight (2.2 lb = 1 kg)
  • 11.5 kg / 25 lb 5.3 oz (25.33 lb)
  • Author
  • Model page created by Zenonas Langaitis. See "Data change" for further contributors.
