• Country
• Poland

• Manufacturer / Brand
• Unitra DIORA - Radiowerk Dzierzoniow,

• Year
• 1959

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 106692

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• ECC85 ECH81 EBF89 EF80 EM80 or EM84 EL84

• Number of Transistors

• Semiconductors
• SPS-6B-250-100

• Main principle
• Superheterodyne (common); ZF/IF 465/10700 kHz

• Tuned circuits
• 6 AM circuit(s)     9 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 127; 220 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Calypso 62127 - Unitra DIORA - Radiowerk

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 580 x 302 x 237 mm / 22.8 x 11.9 x 9.3 inch

• Notes

• OIRT-FM band 64.5 - 73 MHz.

• Net weight (2.2 lb = 1 kg)
• 10 kg / 22 lb 0.4 oz (22.026 lb)

• Price in first year of sale
• 2,100.00 zt

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
