Taraban 2 DMP-602
Unitra DIORA - Radiowerk Dzierzoniow,
- Country
- Poland
- Manufacturer / Brand
- Unitra DIORA - Radiowerk Dzierzoniow,
- Year
- 1985 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 106994
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 5
- Main principle
- Superheterodyne (common); ZF/IF 465/10700 kHz
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Taraban 2 DMP-602 - Unitra DIORA - Radiowerk
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 540 x 157 x 185 mm / 21.3 x 6.2 x 7.3 inch
- Notes
-
Der Taraban 2 DMP-602 hat Anschlüsse für TA und TB, sowie für einen Lautsprecher. FM nach OIRT.
- Source of data
- -- Collector info (Sammler)
- Author
- Model page created by Franz Scharner. See "Data change" for further contributors.
