CB-Mobilfunkgerät M54FM

DNT Drahtlose Nachrichtentechnik; Dietzenbach

Data
Forum
Pictures
Collections

  • Year
  • 1983
  • Category
  • Citizen Band Equipment
  • Radiomuseum.org ID
  • 125569

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superhet, double/triple conversion; ZF/IF 10700/455 kHz
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Storage Battery for all (e.g. for car radios and amateur radios) / 13,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Power out
  • 0.5 W (max.)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: CB-Mobilfunkgerät M54FM - DNT Drahtlose
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Notes

  • 22 Kanal, 27-MHz-Band, FM, HF-Ausgangsleistung 4 Watt, digitale Kanalanzeige, Instrument für RX- und TX-Anzeige.

    FTZ Zulassungsnummer PR27D-FM4M80

    In Deutschland nur mir 0,5 Watt Senderausgangsleistung zugelassen und ausgeliefert.

  • Price in first year of sale
  • 98.00 DM
  • Mentioned in
  • -- Original prospect or advert
  • Author
  • Model page created by Karlheinz Fischer. See "Data change" for further contributors.
