1225

• Country
• Germany

• Manufacturer / Brand
• Dual, Gebr. Steidinger; St. Georgen/Schwarzwald

• Year
• 1974–1976

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 85648

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 110-130; 220-240 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: 1225 - Dual, Gebr. Steidinger; St.

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 329 x 128 x 274 mm / 13 x 5 x 10.8 inch

• Notes
• Geschwindigkeiten: 33/45 UpM, Stereo-Magnetsystem DMS200, Übertragungsbereich: 20···20000 Hz.

• Net weight (2.2 lb = 1 kg)
• 4.1 kg / 9 lb 0.5 oz (9.031 lb)

• Price in first year of sale
• 166.00 DM

• Source of data
• Handbuch VDRG 1974/1975 / Radiokatalog Band 2, Ernst Erb

• Mentioned in
• Handbuch VDRG 1975/1976

• Author
• Model page created by Ervé Leclercq. See "Data change" for further contributors.
