• Country
• Germany

• Manufacturer / Brand
• Dual, Gebr. Steidinger; St. Georgen/Schwarzwald

• Year
• 1987–1991

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 204044

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• PLL, Phase-locked loop

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Audiophile Concept CT 5750 - Dual, Gebr. Steidinger; St.

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 440 x 92 x 305 mm / 17.3 x 3.6 x 12 inch

• Notes
• Hifi-Stereo-Quarz-Synthesizer-Tuner, 2 Wellenbereiche (FM/MW) 20 Speicherplätze bleiben bei Netzausfall erhalten, Bandbreitenumschaltung, Sendersuchlauf auto/man, Muting-Stummschaltung zwischen den Sendern, 5-stellige digitale Frequenz-Anzeige, Alu-Frontblende, schwarz.

• Net weight (2.2 lb = 1 kg)
• 4.2 kg / 9 lb 4 oz (9.251 lb)

• Source of data
• - - Data from my own collection

• Mentioned in
• -- Original prospect or advert

• Author
• Model page created by Felix Kreitlow. See "Data change" for further contributors.
