CV1280 278156
Dual, Gebr. Steidinger; St. Georgen/Schwarzwald
- Country
- Germany
- Manufacturer / Brand
- Dual, Gebr. Steidinger; St. Georgen/Schwarzwald
- Year
- 1986 ?
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 148086
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 230 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 140 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: CV1280 278156 - Dual, Gebr. Steidinger; St.
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 440 x 110 x 245 mm / 17.3 x 4.3 x 9.6 inch
- Notes
- Ausgangsleistung 2 x 70 Watt Sinus
- Source of data
- - - Data from my own collection
- Author
- Model page created by Heribert Jung. See "Data change" for further contributors.
