DK 200-2

Dual, Gebr. Steidinger; St. Georgen/Schwarzwald

Data
Forum
Pictures
Collections

  • Year
  • 1972
  • Category
  • Loudspeaker, headphone or earphone
  • Radiomuseum.org ID
  • 123589

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Wave bands
  • - without
  • Power type and voltage
  • No Power needed
  • Loudspeaker
  • - Is a Headphone or Earphone
  • Material
  • Various materials
  • from Radiomuseum.org
  • Model: DK 200-2 - Dual, Gebr. Steidinger; St.
  • Shape
  • Miscellaneous shapes - described under notes.
  • Notes

  • Dual High Fidelity Stereo Headset Model DK 200-2.
    Freq. response: 20-17000 Hz, Impedance: 400 ohm per system.
    Sensitivity: 0,2 mW per system, corresponding to 0.28 V for 100 dB (20 µbar) sound pressure at 400 ohm.
    Max. power output: 100 mW per system, corresponding to 6.34 V at 400 ohm.
    Distortion (at 1000 Hz): <1% at 120 dB (200 µbar).
    Net weight: aproximate 0.85 lbs.
    DK 200-2 with cable and 1/4 in. coaxial phone plug.

    See also:
    Dual DK 200-1 with cable and speaker type plug per DIN 41529.

  • Net weight (2.2 lb = 1 kg)
  • 0.4 kg / 0 lb 14.1 oz (0.881 lb)
  • Mentioned in
  • Dual Stereo and High Fidelity Products 1972/73 leaflet.
  • Author
  • Model page created by J. Virgilio Santos. See "Data change" for further contributors.
