• Country
• Germany

• Manufacturer / Brand
• Dual, Gebr. Steidinger; St. Georgen/Schwarzwald

• Year
• 1988 ?

• Category
• Loudspeaker, headphone or earphone

• Radiomuseum.org ID
• 280100

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• No Power needed

• Loudspeaker
• 3 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: HiFi 3-Way-Box CL 9040 Ident-Nr. 42 224 - Dual, Gebr. Steidinger; St.

• Shape
• Console with any shape - in general

• Dimensions (WHD)
• 260 x 560 x 280 mm / 10.2 x 22 x 11 inch

• Notes

• Dual 3-Way Speaker System Model CL-9040 (Ident-Nr.: 42 224)
  Nominal/Music Power: 100/130 Watts
  87dB/W/m
  30 - 22000Hz
  Impedance 8 Ohms
  Drivers:
  1x Woofer 200mm
  1x Midrange 125mm
  1x Highrange 25mm
  Detachable Grille




• Net weight (2.2 lb = 1 kg)
• 12 kg / 26 lb 6.9 oz (26.432 lb)

• Mentioned in
• -- Original prospect or advert (Dual Katalog 1991 - HiFi, TV, Video)

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
