• Country
• Germany

• Manufacturer / Brand
• Dual, Gebr. Steidinger; St. Georgen/Schwarzwald

• Year
• 1979

• Category
• Loudspeaker, headphone or earphone

• Radiomuseum.org ID
• 271234

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• No Power needed

• Loudspeaker
• 3 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: HiFi - Dreiweg-Box CL 281 - Dual, Gebr. Steidinger; St.

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 300 x 500 x 220 mm / 11.8 x 19.7 x 8.7 inch

• Notes

• Dual 3-Weg Lautsprecherbox Modell CL 281.
  Nennbelastbarkeit /Musikbelastbarkeit: 80 / 120 Watt
  4 Ohm, 87dB/W/m
  30 - 25000Hz
  Eigenresonanz 75 Hz
  Klirrfaktor <1 (100-25000Hz)
  Bruttovolumen 33 Liter
  Bestückung:
  1x Tiefton 245mm
  1x Mittelton 100mm
  1x Kalotten-Hochton 19mm
  3 LC-Frequenzweichen:
  Trennfrequenzen 800/3000Hz, 12dB/Okt
  Made in Germany

• Net weight (2.2 lb = 1 kg)
• 8.5 kg / 18 lb 11.6 oz (18.722 lb)

• Mentioned in
• - - Manufacturers Literature (Dual Katalog 2/1979)

• Author
• Model page created by a member from A. See "Data change" for further contributors.
