- Country
- Italy
- Manufacturer / Brand
- Ducati, SSR (Società Scientifica Radio Brevetti Ducati); Bologna
- Year
- 1943
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 260883
Pubblicazione bimestrale Ducati
- Number of Tubes
- 3
- Main principle
- Audio-Amplification; something special ? Please give information (notes)
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 110; 220 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Material
- Metal case
- from Radiomuseum.org
- Model: Dufono 10102 - Ducati, SSR Società
- Shape
- Chassis only or for «building in»
- Dimensions (WHD)
- 190 x 260 x 90 mm / 7.5 x 10.2 x 3.5 inch
- Notes
-
Amplificatore per sistema interfonico di uffici, fabbriche... e caserme! ( fino a15 utenti)
- Net weight (2.2 lb = 1 kg)
- 3.7 kg / 8 lb 2.4 oz (8.15 lb)
- Mentioned in
- Il Manuale del Radiomeccanico
