- Country
- Italy
- Manufacturer / Brand
- Ducati, SSR (Società Scientifica Radio Brevetti Ducati); Bologna
- Year
- 1952 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 136211
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Main principle
- Superheterodyne (common); ZF/IF 467 kHz
- Wave bands
- Broadcast plus more than 2 Short Wave bands.
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 140; 160; 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 13 cm = 5.1 inch
- Power out
- 3 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: RR4350 - Ducati, SSR Società
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 520 x 290 x 180 mm / 20.5 x 11.4 x 7.1 inch
- Net weight (2.2 lb = 1 kg)
- 5.5 kg / 12 lb 1.8 oz (12.115 lb)
- Mentioned in
- - - Data from my own collection
- Literature/Schematics (1)
- -- Schematic
- Author
- Model page created by Giuseppe Lucenti. See "Data change" for further contributors.
