• Country
• United States of America (USA)

• Manufacturer / Brand
• DuMont Labs, Allen B., Inc.

• Year
• 1939

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 126123

• • alternative name: Dumont Television & Radio

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 22

• Valves / Tubes

• Main principle
• Superheterodyne (common)

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 110 Volt

• Loudspeaker
• Permanent or electro-dynamic (moving coil), system not known yet.

• Material
• Wooden case

• from Radiomuseum.org
• Model: 183 - DuMont Labs, Allen B., Inc.

• Shape
• Console with any shape - in general

• Dimensions (WHD)
• 21 x 38.25 x 25.75 inch / 533 x 972 x 654 mm

• Notes
• 14" 441 lines b/w TV, 4 channel VHF band I tuner, grained walnut cabinet.

• Source of data
• -- Original prospect or advert

• Author
• Model page created by a member from A. See "Data change" for further contributors.
