• Country
• Germany

• Manufacturer / Brand
• Dynacord (W. Pinternagel); Straubing

• Year
• 1964

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 75348

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• ECC808 ECC83 ECC83 EL84 EL84

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 110-240 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Metal case

• from Radiomuseum.org
• Model: MV17 - Dynacord W. Pinternagel;

• Dimensions (WHD)
• 260 x 110 x 220 mm / 10.2 x 4.3 x 8.7 inch

• Notes
• Mischverstärker MV 17, drei mischbare Kanäle, acht Eingänge, getrennte Höhen-und Tiefenregelung, Summenregler, Pegelregler für vier Eingänge, alle Eingänge mit und ohne Echo bzw. Hall schaltbar, Klirrfaktor 1% bei 1 kHz und 12 Watt.

• Net weight (2.2 lb = 1 kg)
• 5.7 kg / 12 lb 8.9 oz (12.555 lb)

• Price in first year of sale
• 425.00 DM

• Source of data
• Radiokatalog Band 2, Ernst Erb

• Author
• Model page created by Peter Breu. See "Data change" for further contributors.
