• Country
• United States of America (USA)

• Manufacturer / Brand
• B&K (Precision), Dynascan Corp., Cobra Electronics; Chicago, IL and Yorba Linda, CA

• Year
• 1979

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 255905

• • alternative name: B&K Manufacturing Company

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 2

• Semiconductors
• 2N6254 2N5496

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 110/220 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: B+K Precision Regulated DC Power Supply 1601 - B&K Precision, Dynascan Corp.,

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 14 x 3 x 10 inch / 356 x 76 x 254 mm

• Notes

• Dynascan Regulated DC Power Supply 1601.
  Output voltage 0-50 VDC, continuously variable. Two ranges, 0-25 and 0-50 VDC.
  Output current 0-2 A. Four ranges, 0-50 mA, 0-0.2 A, 0-0.5 A and 0-2 A.

• Net weight (2.2 lb = 1 kg)
• 11 lb (11 lb 0 oz) / 4.994 kg

• Mentioned in
• -- Original-techn. papers.

• Author
• Model page created by Jorge Juan Stark. See "Data change" for further contributors.
