Capacitor Analyst B&K 801

• Country
• United States of America (USA)

• Manufacturer / Brand
• B&K (Precision), Dynascan Corp., Cobra Electronics; Chicago, IL and Yorba Linda, CA

• Year
• 1965

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 208209

• • alternative name: B&K Manufacturing Company

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 2

• Valves / Tubes
• ECC82 ECC82

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 117 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Capacitor Analyst B&K 801 - B&K Precision, Dynascan Corp.,

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 33 x 13 x 17 inch / 838 x 330 x 432 mm

• Notes

• Checks capacitor value from 25 pfd to 100 mfd.

• Net weight (2.2 lb = 1 kg)
• 7 lb 0 oz (7 lb) / 3.178 kg

• Price in first year of sale
• 99.95 $

• Mentioned in
• Advert in "Radio Electronics" April 1965

• Literature/Schematics (1)
• - - Data from my own collection

• Author
• Model page created by Abu Bakar. See "Data change" for further contributors.
