Dyna-Jet Tube Tester B&K 747

• Country
• United States of America (USA)

• Manufacturer / Brand
• B&K (Precision), Dynascan Corp., Cobra Electronics; Chicago, IL and Yorba Linda, CA

• Year
• 1971

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 103049

• • alternative name: B&K Manufacturing Company

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 1

• Semiconductors
• 2N5458

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 117 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Dyna-Jet Tube Tester B&K 747 - B&K Precision, Dynascan Corp.,

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 520 x 140 x 300 mm / 20.5 x 5.5 x 11.8 inch

• Notes
• Gehäuse in Form eines Aktenkoffers mit Tragegriff. Vollständiger Modellname: Dyna-Jet solid state dynamic mutual conductance tube tester.

• Source of data
• - - Data from my own collection
