- Country
- United States of America (USA)
- Manufacturer / Brand
- B&K (Precision), Dynascan Corp., Cobra Electronics; Chicago, IL and Yorba Linda, CA
- Year
- 1960 ??
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 171247
-
- alternative name: B&K Manufacturing Company
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 1
- Valves / Tubes
- 6BN8
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 117 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: Dyna Tester 625 - B&K Precision, Dynascan Corp.,
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 380 x 125 x 293 mm / 15 x 4.9 x 11.5 inch
- Notes
-
The Dynascan Dyna Tester 625 is a tube and a CRT tester. It can also measure resistance from 0 to 1M Ω and voltages from 0 to 1000 V AC or DC.
Zusätzlich ist die Messung von Widerständen 0...1 M und Spannungen AC/DC 0...1000 V möglich.
- Net weight (2.2 lb = 1 kg)
- 4.6 kg / 10 lb 2.1 oz (10.132 lb)
- Source of data
- - - Data from my own collection
