• Country
• United States of America (USA)

• Manufacturer / Brand
• B&K (Precision), Dynascan Corp., Cobra Electronics; Chicago, IL and Yorba Linda, CA

• Year
• 1970

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 144318

• • alternative name: B&K Manufacturing Company

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 10

• Semiconductors

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 117 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Metal case

• from Radiomuseum.org
• Model: RF Signal Generator E-200D - B&K Precision, Dynascan Corp.,

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 12.75 x 7.25 x 8 inch / 324 x 184 x 203 mm

• Notes
• B&K Dynascan Precision Solid State Model E-200D RF Signal Generator;
  One 200 µA instrument, for radio & TV aligning, coverage: 100 kHz - 54 MHz in five fundamental bands, 32 MHz - 216 MHz in two harmonic bands, six step attenuator, CW or AM modulation, 400 Hz int. mod., 1 MHz and 100 kHz Xtal calibrator, different power supply versions known, 6 W power consumption.

• Source of data
• -- Original-techn. papers.

• Author
• Model page created by a member from A. See "Data change" for further contributors.
