Mazurka HFC30A

Dynatron Radio Ltd., Maidenhead, Berkshire

Data
Forum
Pictures
Collections

  • Year
  • 1970 ?
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 303994

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 16
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Changer (Record changer)
  • Power type and voltage
  • Alternating Current supply (AC) / 220; 250 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Mazurka HFC30A - Dynatron Radio Ltd.,
  • Shape
  • Tablemodel, low profile (big size).
  • Notes

  • Stereo record player fitted with a 3 speed Garrard 40B autochanger with a Goldring G850 cartridge and diamond stylus and a 2 x 8W transistorised amplifier, housed in a teak plinth with a perspex lid. Bass, treble, balance, loudness and S filter controls. Requires two loudspeakers, not supplied, matching Dynatron 4Ω units recommended.

    Sockets for mono or stereo tape recorder, radio tuner, headphones and for two loudspeakers.

    A similar 'transpower' stereo amplifier chassis is fitted to the Dynatron HFC30M Mazurka record player, and the HFC36 Carnival and HFC37 Carnival record players.

  • Literature/Schematics (1)
  • ERT Service Chart 1809 dated September 16 1971
  • Author
  • Model page created by Howard Craven. See "Data change" for further contributors.
