• Country
• Great Britain (UK)

• Manufacturer / Brand
• Dynatron Radio Ltd., Maidenhead, Berkshire

• Year
• 1970 ?

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 303995

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 16

• Semiconductors
• BC149 or. BC109 BC148 or. BC108 BC148 or. BC108 NKT213 NKT717 NKT212 AL103 AL103 BC149 or. BC109 BC148 or. BC108 BC148 or. BC108 NKT213 NKT717 NKT212 AL103 AL103

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Record Player (not changer)

• Power type and voltage
• Alternating Current supply (AC) / 220; 250 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Wooden case

• from Radiomuseum.org
• Model: Mazurka HFC30M - Dynatron Radio Ltd.,

• Shape
• Tablemodel, low profile (big size).

• Notes

• Stereo record player fitted with a 3 speed Garrard SP25 manual turntable with a Goldring G850 cartridge and diamond stylus and a 2 x 8W transistorised amplifier, housed in a teak plinth with a perspex lid. Bass, treble, balance, loudness and S filter controls. Requires two loudspeakers, not supplied, matching Dynatron 4Ω units recommended.

  Sockets for mono or stereo tape recorder, radio tuner, headphones and for two loudspeakers.

  A similar 'transpower' stereo amplifier chassis is fitted to the Dynatron HFC30A Mazurka record player, and the HFC36 Carnival and HFC37 Carnival record players.

• Literature/Schematics (1)
• ERT Service Chart 1809 dated September 16 1971

• Author
• Model page created by Howard Craven. See "Data change" for further contributors.
