• Country
• Great Britain (UK)

• Manufacturer / Brand
• Dynatron Radio Ltd., Maidenhead, Berkshire

• Year
• 1966 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 103504

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 8

• Semiconductors
• AF115 AF117 AF117 NKT275 NKT773 NKT271 NKT775 NKT272

• Main principle
• Superheterodyne (common); ZF/IF 470 kHz; 4 AF stage(s)

• Tuned circuits
• 5 AM circuit(s)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Dry Batteries / PP9: 2 x 9 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Power out
• 1 W (unknown quality)

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: Rally TP36 - Dynatron Radio Ltd.,

• Shape
• Portable set > 8 inch (also usable without mains)

• Notes

• A battery portable 8 transistor radio housed in a padded vinyl covered wooden cabinet, covering the MW and LW bands. Sockets for earphone and car aerial. The 'car' button switches in separate aerial coils used in conjunction with a car aerial  Elliptical loudspeaker 6 x 4 inches. Transistors 1, 2 and 3 above are in a Mullard type LP1156 Mixer/IF module .

  The same chassis is used in the Dynatron TP37 Rally model which is housed in a teak wooden cabinet.

• Circuit diagram reference
• Radio and TV Servicing books (R&TVS) book

• Mentioned in
• -- Original-techn. papers.

• Literature/Schematics (1)
• Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (1798 dated 7 April 1967)

• Author
• Model page created by Peter Hoddow. See "Data change" for further contributors.
