- Country
- Germany
- Manufacturer / Brand
- EAK, Elektro-Apparatefabrik Köppelsdorf, ex AEG (Sonneberg)
- Year
- 1947 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 172013
ebay, 360720698641, united-pinkynella.
ebay, 360720698641, united-pinkynella.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 468 kHz
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 220; 240 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Super 5/47W - EAK, Elektro-Apparatefabrik
- Shape
- Tablemodel, low profile (big size).
- Notes
-
Radiokatalog Band 2 (Ernst Erb) erwähnt die Modellen Super 5/47W I und Super 5/47W II.
Obwohl es bestimmt auch das Modell Super 5/47W (ohne Suffix) gegeben hat, wird das in der genannten Quelle nicht gelistet. Vermutlich wird hier mit Modell Super 5/47W I das Modell 5/47W (ohne Suffix) gemeint.
