• Country
• Italy

• Manufacturer / Brand
• EAR Radio; Desio (MI)

• Year
• 1949 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 286783

• Number of Tubes
• 5

• Valves / Tubes
• UCH41 UF41 UBC41 UL41 UY41

• Main principle
• Superheterodyne (common); ZF/IF 460 kHz; 2 AF stage(s)

• Wave bands
• Broadcast plus 2 Short Wave bands.

• Power type and voltage
• Alternating Current supply (AC) / 110-220 Volt

• Loudspeaker
• Permanent or electro-dynamic (moving coil), system not known yet. / Ø 18 cm = 7.1 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: Beta - EAR Radio; Desio MI

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 370 x 240 x 200 mm / 14.6 x 9.4 x 7.9 inch

• Author
• Model page created by Carlo Pranzo. See "Data change" for further contributors.
