- Country
- Hungary
- Manufacturer / Brand
- Echo, Vörös Rezső okl. gépészmérnök Rádiólaboratóriuma; Budapest
- Year
- 1941
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 124010
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 480 kHz
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110; 120; 150; 220 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 342V - Echo, Vörös Rezső okl. gépészm
- Shape
- Tablemodel, with any shape - general.
- Notes
-
Speaker: 5W
- Mentioned in
- Rádió Technika 1941.
- Author
- Model page created by Sándor Selyem-Tóth. See "Data change" for further contributors.
