Ekco Gondola RM204
AEI Ekco, Ediswan-Ekco (Aust.) Pty. Ltd.; Sydney, NSW
- Country
- Australia
- Manufacturer / Brand
- AEI Ekco, Ediswan-Ekco (Aust.) Pty. Ltd.; Sydney, NSW
- Year
- 1958
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 160363
-
- Brand: Ekco Australia
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC) / 200-250 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Ekco Gondola RM204 - AEI Ekco, Ediswan-Ekco Aust.
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 390 x 210 x 160 mm / 15.4 x 8.3 x 6.3 inch
- Notes
-
Ekco Gondola RM204;
Tone control, Rola speaker, screw terminals for earth/antenna & pick up in.Colours available in Adriatic Gold, Italian Ivory, Venetian Grey, Florentine Wine, Mediterranean Pink, Rome Red, Grotto Green, Cafe Tan & Sorrento Jade.
Labeled at rear with Ediswan-Ekco & Australian Electronic Industries.
- Net weight (2.2 lb = 1 kg)
- 5.5 kg / 12 lb 1.8 oz (12.115 lb)
- Price in first year of sale
- 26.25 AUS £
- Literature/Schematics (1)
- - - Manufacturers Literature (AEI Ekco Service Information.)
- Author
- Model page created by a member from A. See "Data change" for further contributors.
