Rosabel Radio montaje nº 4
Editorial Bruguera, Radio Montajes; Barcelona
- Country
- Spain
- Manufacturer / Brand
- Editorial Bruguera, Radio Montajes; Barcelona
- Year
- 1955–1960
- Category
- Kit (Parts plus instruction) or building instructions only
- Radiomuseum.org ID
- 298756
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- Alternating Current supply (AC) / 125 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- from Radiomuseum.org
- Model: Rosabel Radio montaje nº 4 - Editorial Bruguera, Radio
- Mentioned in
- -- Original-techn. papers. (Radio Montaje #4)
- Author
- Model page created by Mariano Crucera Ramos. See "Data change" for further contributors.
