- Country
- Italy
- Manufacturer / Brand
- Effedibi Radio, FDB Radio TV, de Benardi, SARE (S.A.R.E.); Torino, Milano
- Year
- 1952 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 180400
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 140; 160; 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 16.5 cm = 6.5 inch
- Power out
- 4 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Artenisia - Effedibi Radio, FDB Radio TV,
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 490 x 285 x 200 mm / 19.3 x 11.2 x 7.9 inch
- Net weight (2.2 lb = 1 kg)
- 5 kg / 11 lb 0.2 oz (11.013 lb)
- External source of data
- Mia Collezione
- Author
- Model page created by Valentino Tancredi. See "Data change" for further contributors.
