• Country
• Germany

• Manufacturer / Brand
• Delphin-Werk Helmut Kretschmar OHG, Pirna; (Ostd.)

• Year
• 1971/1972

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 82797

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 4

• Semiconductors
• GC118 GC116 GC301 GC301 M25/10-0,36

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Rec.Player+Audio.Amp+LS

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 1.5 W (unknown quality)

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: Akzent - Delphin-Werk Helmut Kretschmar

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 340 x 185 x 290 mm / 13.4 x 7.3 x 11.4 inch

• Notes
• Lautsprecher im Deckel. Übertragungsbereich des Verstärkers: 40-15000 Hz, Abtastsystem: KSS 0163. Das Gerät wurde bis 10.04.1972 vom Delphinwerk Pirna produziert, danach wurde die Firma in VEB Phonomat Pirna umbenannt.

• Net weight (2.2 lb = 1 kg)
• 5.8 kg / 12 lb 12.4 oz (12.775 lb)

• Price in first year of sale
• 290.00 Mark

• Source of data
• -- Original prospect or advert / Radiokatalog Band 2, Ernst Erb

• Author
• Model page created by Wolfgang Lill. See "Data change" for further contributors.
