• Country
• United States of America (USA)

• Manufacturer / Brand
• EICO (Electronic Instrument Co.Inc.) Brooklyn

• Year
• 1953 ?

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 314577

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• Storage and/or dry batteries

• Loudspeaker
• - - No sound reproduction output.

• Material
• Bakelite case

• from Radiomuseum.org
• Model: 526 Multimeter - EICO Electronic Instrument Co.

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 3.75 x 6.25 x 2 inch / 95 x 159 x 51 mm

• Notes

• 1000 ohm per volt multimeter with 31 ranges

  This Model 526 is similar to Model 536, but uses 1% resistors for greater accuracy

  There also was a kit version 526-K for $13.90

• Price in first year of sale
• 16.90 USD

• Mentioned in
• Allied Radio Catalog (Knight) (1953, page 71)

• Author
• Model page created by George Papaiz. See "Data change" for further contributors.
