• Country
• United States of America (USA)

• Manufacturer / Brand
• EICO (Electronic Instrument Co.Inc.) Brooklyn

• Year
• 1961

• Category
• Amateur Transmitter (only)

• Radiomuseum.org ID
• 286484

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 3

• Valves / Tubes
• 6DQ6 6CL6 GZ34

• Main principle
• Transmitter

• Wave bands
• Short Wave (SW only)

• Power type and voltage
• Alternating Current supply (AC) / 117 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: 60 Watt CW Transmitter 723 - EICO Electronic Instrument Co.

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 8.5 x 6 x 11.25 inch / 216 x 152 x 286 mm

• Notes

• The Eico 723 is a crystal controlled 60 watt CW only transmitter, mainly for the former novice HAM.

• Net weight (2.2 lb = 1 kg)
• 15 lb (15 lb 0 oz) / 6.810 kg

• Price in first year of sale
• 79.95 USD

• Mentioned in
• QST (February 1961 page 111)

• Author
• Model page created by Wayne Childress. See "Data change" for further contributors.
