FM Tuner HFT90A
EICO (Electronic Instrument Co.Inc.) Brooklyn
- Country
- United States of America (USA)
- Manufacturer / Brand
- EICO (Electronic Instrument Co.Inc.) Brooklyn
- Year
- 1964
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 353975
1968 Eico catalog, page 7.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 8
- Main principle
- Superhet with RF-stage
- Wave bands
- FM Broadcast Band Only
- Power type and voltage
- Alternating Current supply (AC) / 110 - 125 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: FM Tuner HFT90A - EICO Electronic Instrument Co.
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 12 x 3.625 x 8.25 inch / 305 x 92 x 210 mm
- Notes
-
Price does not include metal cover (available for $3.95).
Companion to Eico HF12A amplifier.
- Net weight (2.2 lb = 1 kg)
- 24 lb (24 lb 0 oz) / 10.896 kg
- Price in first year of sale
- 69.95 USD
- Mentioned in
- - - Manufacturers Literature (1968 Eico catalog, page 7)
- Literature/Schematics (1)
- Lafayette Radio Catalog (#640, 1964, page 310, "2 New Quality Monaural Kits" HFT-90AK kit, HFT-90A factory wired.)
- Author
- Model page created by David Erali. See "Data change" for further contributors.
