TV-FM Sweep Generator and Marker 368

• Country
• United States of America (USA)

• Manufacturer / Brand
• EICO (Electronic Instrument Co.Inc.) Brooklyn

• Year
• 1958 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 132425

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• 12AV7 12AT7 12AX7 6AU6 12B4 6X4

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 105-125 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: TV-FM Sweep Generator and Marker 368 - EICO Electronic Instrument Co.

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 13 x 7 x 8.5 inch / 330 x 178 x 216 mm

• Notes
• Instruction Manual 368-1 Frequency range:3MHz-216MHz

• Net weight (2.2 lb = 1 kg)
• 8 kg / 17 lb 9.9 oz (17.621 lb)

• Source of data
• - - Data from my own collection

• Author
• Model page created by John Backscheider. See "Data change" for further contributors.

• Other Models

• Here you find 183 models, 180 with images and 130 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from EICO (Electronic Instrument Co.Inc.) Brooklyn
