Vacuum Tube Voltmeter (VTVM) 250

• Country
• United States of America (USA)

• Manufacturer / Brand
• EICO (Electronic Instrument Co.Inc.) Brooklyn

• Year
• 1960 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 80726

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• 6FY5 6EJ7 6EJ7 6X4 0A2

• Power type and voltage
• Alternating Current supply (AC) / 117 Volt

• from Radiomuseum.org
• Model: Vacuum Tube Voltmeter 250 - EICO Electronic Instrument Co.

• Mentioned in
• -- Schematic

• Author
• Model page created by Bernd Pötzsch. See "Data change" for further contributors.
