- Country
- Great Britain (UK)
- Manufacturer / Brand
- Cossor, A.C.; London
- Year
- 1937
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 191676
From an auction catalogue.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Main principle
- Superhet, IF regeneration; ZF/IF 465/1363 kHz
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 200-250 Volt
- Loudspeaker
- Permanent or electro-dynamic (moving coil), system not known yet. / Ø 10 inch = 25.4 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: 438 - Cossor, A.C.; London
- Shape
- Console, Lowboy (legs < 50 %).
- Notes
- Same chassis as in the 484 model. IF is 465kHz for MW and LW, 1363kHz for SW.
- Source of data
- - - Manufacturers Literature
- Literature/Schematics (1)
- - - Manufacturers Literature
- Author
- Model page created by Howard Craven. See "Data change" for further contributors.
