- Country
- Great Britain (UK)
- Manufacturer / Brand
- Ekco, E.K.Cole Ltd.; Southend-on-Sea
- Year
- 1957 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 225603
Advertising
Advertising
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 11
- Main principle
- Superheterodyne (common); ZF/IF 460 kHz; 5 AF stage(s)
- Tuned circuits
- 8 AM circuit(s)
- Wave bands
- Broadcast plus more than 2 Short Wave bands.
- Power type and voltage
- Alternating Current supply (AC) / 100-150; 200-250 Volt
- Loudspeaker
- 2 Loudspeakers / Ø 10 inch = 25.4 cm
- Power out
- 6 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: A182 - Ekco, E.K.Cole Ltd.; Southend-
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 695 x 430 x 300 mm / 27.4 x 16.9 x 11.8 inch
- Notes
-
Deluxe Export Model featuring Gram/PU input for crystal or magnetic cartridges, noise limiter, push-pull audio output and miniature Magic eye tuning indicator. Model A182B covers LW, MW and six short wave bands.
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Reg Gauci. See "Data change" for further contributors.
