AC85 brown

• Country
• Great Britain (UK)

• Manufacturer / Brand
• Ekco, E.K.Cole Ltd.; Southend-on-Sea

• Year
• 1934

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 78173

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• FC4 or 41MPG AC/VP1 V914 or 2D4A 354V AC/Pen IW3 or UU3

• Main principle
• Superheterodyne (common); ZF/IF 110 kHz

• Tuned circuits
• 7 AM circuit(s)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Alternating Current supply (AC) / 200-250 Volt

• Loudspeaker
• -Loudspeaker incorporated, but system not known.

• Material
• Bakelite case

• from Radiomuseum.org
• Model: AC85 [brown] - Ekco, E.K.Cole Ltd.; Southend-

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 21 x 12.5 x 9.5 inch / 533 x 318 x 241 mm

• Notes
• also a black version and Battery models(B85). Optional wooden stand.

• Source of data
• Radio! Radio!

• Literature/Schematics (1)
• Trader sheet 654

• Author
• Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
