• Country
• Great Britain (UK)

• Manufacturer / Brand
• Ekco, E.K.Cole Ltd.; Southend-on-Sea

• Year
• 1970 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 303925

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 25

• Semiconductors
• AF102 AF121 AF121 AF121 AF121 AF121 BC148 AC187 AC188 AC187 AC188 AD161 BC148 BC148 BC148 AC187 AC188 AC187 AC188 BC148 BC148 BC148 BC148 BC148 AC128

• Main principle
• Superheterodyne (common); ZF/IF 10850 kHz

• Wave bands
• FM Broadcast Band Only

• Details
• Record Player (not changer)

• Power type and voltage
• Alternating Current supply (AC) / 220-240 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 6 W (unknown quality)

• Material
• Various materials

• from Radiomuseum.org
• Model: FM Stereogram SRG607 - Ekco, E.K.Cole Ltd.; Southend-

• Shape
• Miscellaneous shapes - described under notes.

• Notes

• Stereo radiogram fitted with a manual turntable, 2 x 3 watt amplifier and FM tuner with a stereo decoder. The main tuner/amp/gram unit with perspex dust cover is mounted on a floor standing rack. Two supplied large loudspeaker units are stored within the rack housing under the main unit and can be moved and positioned for best stereo effect.

• Literature/Schematics (1)
• ERT Service Chart 1761 dated September 17 1970

• Author
• Model page created by Howard Craven. See "Data change" for further contributors.
