RS2AC RS 2 AC
Ekco, E.K.Cole Ltd.; Southend-on-Sea
- Country
- Great Britain (UK)
- Manufacturer / Brand
- Ekco, E.K.Cole Ltd.; Southend-on-Sea
- Year
- 1931
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 77587
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 3
- Main principle
- TRF with regeneration
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Alternating Current supply (AC) / 200-250 Volt
- Loudspeaker
- Magnetic loudspeaker (reed) generic.
- Material
- Bakelite case
- from Radiomuseum.org
- Model: RS2AC RS 2 AC - Ekco, E.K.Cole Ltd.; Southend-
- Shape
- Tablemodel, Tombstone = decorative upright, not cathedral but can have rounded edges.
- Dimensions (WHD)
- 14 x 16 x 9.25 inch / 356 x 406 x 235 mm
- Notes
- not to be confused with the similar looking M23 or RS2DC.
- Source of data
- Radio! Radio!
- Literature/Schematics (1)
- Trader sheet 733
- Author
- Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
