- Country
- Great Britain (UK)
- Manufacturer / Brand
- Ekco, E.K.Cole Ltd.; Southend-on-Sea
- Year
- 1956
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 200548
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 19
- Valves / Tubes
- PCC84 or 30L1 PCF80 or 30C1 EF85 30F5 30FL1 6/30L2 30FL1 6D2 6/30L2 30P4 U25 U191 30F5 30F5 6D2 6D2 30P12 30P12 CRM141
- Main principle
- Superheterodyne (common)
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- AC/DC-set / 200-250 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: T283 - Ekco, E.K.Cole Ltd.; Southend-
- Shape
- Tablemodel, high profile (upright - NOT Cathedral nor decorative).
- Notes
- Table TV receiver with a 14 inch 405 line b/w CRT and GB Band I/III VHF tuner. Optional "armchair" remote control unit.
- Literature/Schematics (1)
- Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (1278/T115)
- Author
- Model page created by Howard Craven. See "Data change" for further contributors.
