- Country
- Great Britain (UK)
- Manufacturer / Brand
- Ekco, E.K.Cole Ltd.; Southend-on-Sea
- Year
- 1968 ??
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 173128
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 18
- Valves / Tubes
- PCC84 PCF80 EF85 EF85 EF80 EF80 PCL82 PCL84 EF80 EF80 ECC82 ECC82 ECC82 EB91 PCL82 PY88 PL36 EY86
- Main principle
- Superheterodyne (common); ZF/IF 39750/34250 kHz
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 220; 240 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7 inch = 17.8 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: T737 - Ekco, E.K.Cole Ltd.; Southend-
- Shape
- Tablemodel, with any shape - general.
- Notes
- Superheterodyne receiver for use on the CCIR 625 lines 50 fields system. Incorporates a 17" 110º CRT CME 1703. Mains consumption dependent upon the mains supply voltage, 157-175 watts. Frequency range VHF channels 2; 3; 4; 5; 6; 7; 8; 9; 10. Aereal inputs 75 ohms coaxial unbalanced or 300 ohms balanced twin feeder.
- Source of data
- - - Manufacturers Literature
- Author
- Model page created by Antonio Barros-Regada. See "Data change" for further contributors.
