• Country
• Germany

• Manufacturer / Brand
• Elac Electroacustic GmbH; Kiel

• Year
• 1968/1969

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 27422

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 42

• Semiconductors

• Main principle
• Superheterodyne (common); ZF/IF 460/10700 kHz

• Tuned circuits
• 10 AM circuit(s)     15 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110; 127; 220; 240 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Wooden case

• from Radiomuseum.org
• Model: 3200T Körting Ch= 29678 [Nussbaum] - Elac Electroacustic GmbH; Kiel

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 675 x 170 x 235 mm / 26.6 x 6.7 x 9.3 inch

• Notes

• Vollstereo, NF-Verstärker mit zwei Endstufen je 22 W (Sinus).

  Hersteller: Körting Radio-Werke, Grassau/Chiemgau, für Elac GmbH, Kiel.

• Net weight (2.2 lb = 1 kg)
• 10.5 kg / 23 lb 2 oz (23.128 lb)

• Price in first year of sale
• 1,050.00 DM

• External source of data
• erb

• Source of data
• Handbuch VDRG 1968/1969 / Radiokatalog Band 2, Ernst Erb
