Compact C1100 Quadrosound
Elac Electroacustic GmbH; Kiel
- Country
- Germany
- Manufacturer / Brand
- Elac Electroacustic GmbH; Kiel
- Year
- 1975–1977
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 131102
Q: Elac, Service-Unterlagen
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 45
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Details
- Other Combination - see Notes
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Material
- Wooden case
- from Radiomuseum.org
- Model: Compact C1100 Quadrosound - Elac Electroacustic GmbH; Kiel
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 621 x 180 x 429 mm / 24.4 x 7.1 x 16.9 inch
- Notes
- ICs: 3.
Compact-Anlage, auch für Quadrosound-Wiedergabe geeignet. Stereo-NF-Verstärker mit 2 Endstufen je 20 W (Musik);
Phono-Chassis = ELAC 805;
Cassetten-Deck mit DNL-Rauschunterdrückung, Quadrosound-Wiedergabe und Duplo-Stereo möglich.
Anschlüse für Stereo-Tonbandgerät, 2 + 2 Lautsprecher, Kopfhörer, Mikrofon.
Gehäuseausführung Schwarz/Metallic oder Schwarz/Nussbaum.
- Source of data
- Handbuch VDRG 1976/1977
- Mentioned in
- Handbuch VDRG 1975/1976
- Author
- Model page created by Bernd P. Kieck. See "Data change" for further contributors.
