• Country
• Germany

• Manufacturer / Brand
• Elac Electroacustic GmbH; Kiel

• Year
• 1953–1959

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 20113

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 110; 220 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Bakelite or Plastics (type unknown)

• from Radiomuseum.org
• Model: Miracord 6 PW6 - Elac Electroacustic GmbH; Kiel

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 329 x 267 x 271 mm / 13 x 10.5 x 10.7 inch

• Notes
• 3 Geschwindigkeiten; Kristall-System.

  Ausführungen: PW6 bis Fabriknummer 102114, PW6B bis Fabriknummer 178599, PW6C bis Fabriknummer 178506, ab Fabriknummer 178600 mit 4 Geschwindigkeiten.

  Parallelgerät zum AGA PW6 und Polydor PW6.

• Net weight (2.2 lb = 1 kg)
• 3.9 kg / 8 lb 9.4 oz (8.59 lb)

• Price in first year of sale
• 172.00 DM

• External source of data
• Erb

• Source of data
• HdB d.Rdf-& Ferns-GrH 1953/54 / Radiokatalog Band 2, Ernst Erb
