Miracord 50H
Elac Electroacustic GmbH; Kiel
- Country
- Germany
- Manufacturer / Brand
- Elac Electroacustic GmbH; Kiel
- Year
- 1966–1972
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 113192
Click on the schematic thumbnail to request the schematic as a free document.
- Wave bands
- - without
- Details
- Record Player (perh.Changer)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- - For headphones or amp.
- from Radiomuseum.org
- Model: Miracord 50H - Elac Electroacustic GmbH; Kiel
- Shape
- Chassis only or for «building in»
- Dimensions (WHD)
- 368 x 235 x 317 mm / 14.5 x 9.3 x 12.5 inch
- Notes
- Reibradantrieb; 4 Geschwindigkeiten; Stereo-Magnet-System mit Diamant-Nadel;Tonarm: Metallarm (4Seitiges Rohr), Tonkopfschlitten TAS 2, Auflagegewicht einstellbar von 0 - 6 p. am Gewicht; Übertragungsbereich: 20···20000 Hz.; Antiskating einstellbar; Tonarmlift System: ELAC STS 155-17 bis STS 455
- Net weight (2.2 lb = 1 kg)
- 6.5 kg / 14 lb 5.1 oz (14.317 lb)
- Price in first year of sale
- 438.00 DM
- Source of data
- Handbuch VDRG 1966/1967
- Author
- Model page created by Bernd P. Kieck. See "Data change" for further contributors.
