• Country
• Germany

• Manufacturer / Brand
• Elac Electroacustic GmbH; Kiel

• Year
• 1975–1977

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 78617

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Wooden case

• from Radiomuseum.org
• Model: PC810 - Elac Electroacustic GmbH; Kiel

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 435 x 185 x 350 mm / 17.1 x 7.3 x 13.8 inch

• Notes
• Geschwindigkeiten: 33/45 UpM; Antiskating; vorbereitet für CD 4-Quadrofonie; Magnetsystem ELAC STS145-17 mit Diamant D155-17; Übertragungsbereich: 20-20000 Hz.
  Stroboskop-Drehzahlfeinregulierung, Tonarmlift, Drucktastensteuerung, Freilaufachse.

• Net weight (2.2 lb = 1 kg)
• 6.3 kg / 13 lb 14 oz (13.877 lb)

• Source of data
• Handbuch VDRG 1976/1977 / Radiokatalog Band 2, Ernst Erb

• Mentioned in
• Handbuch VDRG 1975/1976

Bedienungsanleitung Deutsch

2660 KB

• Documents regarding this model

• Author
• Model page created by Peter Böhm. See "Data change" for further contributors.
