• Country
• Spain

• Manufacturer / Brand
• Comercial Radio Bertrán; Electrónica Bertrán; ELBE; Barcelona

• Year
• 1957 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 159395

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• EF41 or EAF42 EBC41 EBC41 EL84 or EL41 EL84 or EL41 EZ80

• Main principle
• Superheterodyne (common); ZF/IF 470 kHz; 2 AF stage(s)

• Wave bands
• Broadcast plus more than 2 Short Wave bands.

• Details
• Record Player (not changer)

• Power type and voltage
• Alternating Current supply (AC) / 125 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 inch = 25.4 cm

• from Radiomuseum.org
• Model: 8561 - Comercial Radio Bertrán;

• Price in first year of sale
• 3,811.00 ESP

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
